Slip Type Elevator

Slip type elevators are holding and hoisting tools for handling
drill pipe, small casing and tubing in oil and gas field. They are
especially fit to integral joint tubing, non-coupled casing,
electric submersible pump and other tubular goods.
They feature four slip designs which give an optimum contact on the
pipe to prevent bottlenecking and gauge damage. The "YC" type
elevator is capable of handling dual tubing strings. All type "Y"
series elevator operate with the latch lock combination for safety.
The "YC" provide a 7" insert contact to grip your casing or tubing.
They
are designed and manufactured according to APl Spec
8A/8C-specification for drilling and production Hoisting Equipment .
|
Model |
Pipe size |
Max .load |
|
in |
mm |
kN |
Tons |
|
YT |
1.315-3 1/2 |
33.4-88.9 |
670 |
75 |
|
YC |
3 1/2-7 |
88.9-177.8 |
670 |
75 |
|
MYC |
3 1/2~7 |
89~178 |
1130 |
125 |
|
HYC |
2 7/8~7 5/8 |
89~194 |
1800 |
200 |
|
HYT |
2 3/8-3 1/2 |
60.3-88.9 |
1350 |
150 |
|
MYT |
1.315-2 7/8 |
33.4-73 |
360 |
70 |
|
LYT |
1.05-2 1/16 |
26.7-52.4 |
180 |
20 |
|
