Casing Elevator / Spiders Specifications
QD（BJ）
and SE(VARCO) pneumatic casing elevator/spider is applicable for
casing of 60~340mm（23/8~133/8
in). It features labor saving, safety and pneumatic operation,
and it is a kind of ideal tool for casing operation. It is
designed and manufactured according to API Spec 8A
“Specification for Drilling and Production Hoisting Equipment”.
|
Model |
QD450(API500) |
QD315(API350) |
QD135(API150) |
|
Applicable range |
mm |
113-340 |
113-340 |
60-139.7 |
|
in |
41/2-133/8 |
41/2-133/8 |
23/8-51/2 |
|
Rated load |
kN |
4500 |
3150 |
1350(31/2) 900(51/2) |
|
US ton |
500 |
350 |
150(31/2) 100(51/2) |
|
Pressure |
MPa |
0.5-0.9 |
0.5-0.9 |
0.5-0.9 |
|
psi |
72-130 |
72-130 |
72-130 |
|
Size |
elevator |
mm |
1390*1290*915 |
1335*1040*806 |
990*645*550 |
|
in |
55*51*36 |
52.5*41*31.7 |
39*25.4*21.6 |
|
spider |
mm |
1390*1290*970 |
1335*1040*872 |
810*730*560 |
|
in |
55*51*38 |
52.5*41*34.2 |
31.9*28.7*22 |
|
Weight |
kg |
9900 |
7550 |
1430 |
|
lb |
21820 |
16640 |
3152 |
VARCO
Hinged Casing Spiders
The Hinged Casing Spider has a capacity of 200 or 500 Tons,Without
insert bowls,will handle 185/8 and 20 inch casing.Insert bowls are
available,and alone or in combination,can handle 23/8-85/8,95/8-103/4,113/4-133/8,16
inch diameter casing.
BAASH ROSS CASING SPIDER
The Bass-Ross
200 ton hinged casing spider will fit most casing handling
operations. It can be placed on the rotary table, mounted on a
platform which replaces the rotary table, or supported by cribbing,
depending upon the auxiliary equipments and procedure to be
followed. Spider Bushing for handling casing 9"OD and larger are
equipped with a spherical diameter tapered bore. All spiders
bushing to handle 8 5/8" OD casing and smaller have a tapered bore
dimensionally the same as the API Standard rotary master Bushing and
will accommodate any standard rotary slip.
The
tapper of casing spider, UC-3 casing slip and insert bowl is 3 inch/
ft for size above 8 5 /8", 4inch/ ft for size below 8 5/8"(include 8
5/8").
|
MODEL |
TUBULAR OD inch |
TAPPER |
RATED CAPACITY(SHORT TONS) |
|
13 3/8”/200 |
7-8 5/8 |
1:3 |
200 |
|
9-13 3/8 |
1:4 |
|
20/200 |
7- 8 5/8 |
1:3 |
|
9-20 |
1:4 |
|
30/200 |
16-30 |
1:4 |
|
36/200 |
18 5/8-36 |
1:4 |
|
30/500 |
16-30 |
1:3 |
500 |
|
36/500 |
18 5/8-36 |
1:3 |
|
20/500 |
2 3/8-20 |
1:3 |
|
