Single Joint Elevator
We have three type of single joint elevator. SJ, SP, and SJX
Single joint elevators are designed and manufactured according to
API Spec 8A-Specification for Drilling and Production Hoisting
Equipment. The single joint elevator is designed to enable the
drilling rig crew to hoist up the tubular safely to rig floor
without damage the shoulder and threads.
SJ
|
Pipe size |
MAX. LOAD |
|
In |
mm |
kN |
tons |
|
2 3/8-5 3/4 |
60.3-146.1 |
35 |
4 |
|
6-14 |
152.4-355.6 |
45 |
5 |
|
16-36 |
406.4-914.4 |
53 |
6 |
SP
|
TYPE |
PIPE(In) |
kN |
tons |
|
SP5 |
2 3/8-10 3/4 |
45
|
5
|
|
SP12 |
2 3/8-4 1/2” |
|
SP18 |
2 7/8-6 5/8” |
SJX
|
TYPE |
PIPE(In) |
kN |
tons |
|
SJX-5 |
2 3/8-4 1/2 |
45
|
5
|
|
SJX-5 |
4 1/2”-7” |
|
SJX-5 |
7-10” |
|
SJX-5 |
10-14 |
|
